Data Guard, Easy Connect and the Observer for multiple configurations

Posted on by
4

EZConnect

One of the challenges of automation in bin Oracle Environments is dealing with tnsnames.ora files.
These files might grow big and are sometimes hard to distribute/maintain properly.
The worst is when manual modifications are needed: manual operations, if not made carefully, can screw up the connection to the databases.
The best solution is always using LDAP naming resolution. I have seen customers using OID, OUD, Active Directory, openldapd, all with a great level of control and automation. However, some customer don’t have/want this possibility and keep relying on TNS naming resolution.
When Data Guard (and eventually RAC) are in place, the tnsnames.ora gets filled by entries for the DGConnectIdentifiers and StaticConnectIdentifier. If I add the observer, an additional entry is required to access the dbname_CFG service created by the Fast Start Failover.

Actually, all these entries are not required if I use Easy Connect.

My friend Franck Pachot wrote a couple of nice blog posts about Easy Connect while working with me at CERN:
https://medium.com/@FranckPachot/19c-easy-connect-e0c3b77968d7

https://medium.com/@FranckPachot/19c-ezconnect-and-wallet-easy-connect-and-external-password-file-8e326bb8c9f5

Basic Data Guard configuration

The basic configuration with Data Guard is quite simple to achieve with Easy Connect. In this examples I have:
– The primary database TOOLCDB1_SITE1
– The duplicated database for standby TOOLCDB1_SITE2

After setting up the static registration (no Grid Infrastructure in my lab):

and copying the passwordfile, the configuration can be created with:

That’s it.

Now, if I want to have the configuration observed, I need to activate the Fast Start Failover:

With just two databases, FastStartFailoverTarget is not explicitly needed, but I usually do it as other databases might be added to the configuration in the future.
After that, the broker complains that FSFO is enabled but there is no observer yet:



Observer for multiple configurations

This feature has been introduced in 12.2 but it is still not widely used.
Before 12.2, the Observer was a foreground process: the DBAs had to start it in a wrapper script executed with nohup in order to keep it live.
Since 12.2, the observer can run as a background process as far as there is a valid wallet for the connection to the databases.
Also, 12.2 introduced the capability of starting multiple configurations with a single dgmgrl command: “START OBSERVING”.

For more information about it, you can check the documentation here:
https://docs.oracle.com/en/database/oracle/oracle-database/19/dgbkr/using-data-guard-broker-to-manage-switchovers-failovers.html#GUID-BC513CDB-1E06-4EB3-9FE1-E1331E15E492

How to set it up with Easy Connect?

First, I need a wallet. And here comes the first compromise:
Having a single dgmgrl session to start all my configurations means that I have a single wallet for all the databases that I want to observe.
Fair enough, all the DBs (CDBs?) are managed by the same team in this case.
If I have only observers on my host I can easily point to the wallet from my central sqlnet.ora:

Otherwise I need to create a separate TNS_ADMIN for my observer management environment.
Then, I create the wallet:

Now I need to add the connection descriptors.

Which connection descriptors do I need?
The Observer uses the DGConnectIdentifier to keep observing the databases, but needs a connection to both of them using the TOOLCDB1_CFG service (unless I specify something different with the broker configuration property ConfigurationWideServiceName) to connect to the configuration and get the DGConnectIdentifier information. Again, you can check it in the doc. or the note Oracle 12.2 – Simplified OBSERVER Management for Multiple Fast-Start Failover Configurations (Doc ID 2285891.1)

So I need to specify three secrets for three connection descriptors:

The first one will be used for the initial connection. The other two to observe the Primary and Standby.
I need to be careful that the first EZConnect descriptor matches EXACTLY what I put in observer.ora (see next step) and the last two match my DGConnectIdentifier (unless I specify something different with ObserverConnectIdentifier), otherwise I will get some errors and the observer will not observe correctly (or will not start at all).

The dgmgrl needs then a file named observer.ora.
$ORACLE_BASE/admin/observers or the central TNS_ADMIN would be good locations, but what if I have observers that must be started from multiple Oracle Homes?
In that case, having a observer.ora in $ORACLE_HOME/network/admin (or $ORACLE_BASE/homes/{OHNAME}/network/admin/ if Read-Only Oracle Home is enabled) would be a better solution: in this case I would need to start one session per Oracle Home

The content of my observer.ora must be something like:

This is the example for my configuration, but I can put as many (CONFIG=…) as I want in order to observe multiple configurations.
Then, if everything is configured properly, I can start all the observers with a single command:

Troubleshooting

If the observer does not work, sometimes it is not easy to understand the cause.

  • Has SYSDG been granted to SYSDG user? Is SYSDG account unlocked?
  • Does sqlnet.ora contain the correct wallet location?
  • Is the wallet accessible in autologin?
  • Are the entries in the wallet correct? (check with “sqlplus /@connstring as sysdg”)

Missing pieces

Here, a few features that I think would be a nice addition in the future:

  • Awareness for the ORACLE_HOME to be used for each observer
  • Possibility to specify a different TNS_ADMIN per observer (different wallets)
  • Integration with Grid Infrastructure (srvctl add observer…) and support for multiple observers

—

Ludovico

Oracle Clusterware Services Status at a glance, fast!

Posted on by
4

If you use Oracle Clusterware or you deploy your databases to the Oracle Cloud, you probably have some application services defined with srvctl for your database.

If you have many databases, services and nodes, it might be annoying, when doing maintenance or service relocation, to have a quick overview about how services are distributed across the nodes and what’s their status.

With srvctl (the official tool for that), it is a per-database operation:

If you have many databases, you have to run db by db.

It is also slow! For example, this database has 20 services. Getting the status takes 27 seconds:

Instead of operating row-by-row (get the status for each service), why not relying on the cluster resources with crsctl and get the big picture once?

crsctl stat res -f  returns a list of ATTRIBUTE_NAME=value for each service, eventually more than one if the service is not singleton/single instance  but uniform/multi instance.

By parsing them with some awk code can provide nice results!

STATE, INTERNAL_STATE and TARGET are useful in this case and might be used to display colours as well.

  • Green: Status ONLINE, Target ONLINE, STABLE
  • Black: Status OFFLINE, Target OFFLNE, STABLE
  • Red: Status ONLINE, Target OFFLINE, STABLE
  • Yellow: all other cases

Here’s the code:

Here’s what you can expect, for 92 services distributed on 4 nodes and a dozen of databases (the output is snipped and the names are masked):

I’d be curious to know if it works well for your environment, please comment here. 🙂

Thanks

—

Ludo

Oracle Home Management – part 3: Strengths and limitations of Rapid Home Provisioning

Posted on by
8

In the previous post I mentioned that having a central repository storing the Golden Images would be the best solution for the Oracle Home provisioning.

In this context, Oracle provides Rapid Home Provisioning: a product included in Oracle Grid Infrastructure that automates home provisioning and patching of Oracle Database and Grid Infrastructure Homes, databases and also generic software.

rhp-conceptOracle Rapid Home Provisioning simplifies tremendously the software provisioning: you can use it to create golden images starting from existing installations and then deploy them locally, across different nodes, on local or remote clusters, standalone servers, etc.

Having a central store with enforced naming conventions ensures software standardization across the whole Oracle farm, and makes patching easier with less risks. Also, it allows to patch existing databases, moving them to Oracle Homes with a higher patch level, and taking care of service draining and rolling upgrades when RAC or RAC One Node deployments exist. Multiple databases can be patched in a single batch using one single rhpctl command.

I will not explain the technical details of Rapid Home Provisioning implementation operation. I already did a webinar a couple of years ago for the RAC SIG:

Burt Clouse, the RHP product manager, did a presentation as well about Rapid Home Provisioning 12c Release 2, that highlights some new features that the product was missing in the first release:

More details about the new features can be found here:

https://blogs.oracle.com/db_maintenance/whats-new-in-122-for-rapid-home-provisioning-and-maintenance

Close to be the perfect product, but…

If rapid home provisioning is so powerful, what makes it less appealing for most users?

In my opinion (read: very own personal opinion 🙂 ), there are two main factors:

First: The technology stack RHP is relying on is quite complex

Although Rapid Home Provisioning 12c Release 2 allows Oracle Home deployments on standalone servers (it was not the case with 12c Release 1), the Rapid Home Provisioning sever itself relies on Oracle Grid Infrastructure 12cR2. That means that there must be skills in the company to manage the full stack: Clusterware, ASM, ACFS, NFS, GNS, SCAN, etc. as well as the RHP Server itself.

Second: remote provisioning requires Lifecycle Management Pack (extra-cost) option licensed on all the RHP targets

If Oracle Homes are deployed on the same cluster that hosts the RHP Server, the product can be used at no extra cost. But if you have many clusters, or using standalone servers for your Oracle databases, then RHP can become pricey very quickly: the price per processor for Lifecycle Management Pack is 12’000$, plus support (pricelist April 2018). So, buying this management pack just to introduce Rapid Home Provisioning in your company might be an excessive investment.

Of course, depending on your needs, you can evaluate it and leverage its full potential and make a bigger return of investment.

Or, you might explore if it is viable to configure each cluster as Rapid Home Provisioning Server: in this case it would be free, but it will have the additional complexity layer on all your clusters.

For small companies, simple architectures and especially where Standard Edition is deployed (no Management Pack for Standard Edition!), a self-made, simpler solution might be a better choice.

In the next post, before going into the details of a hypothetical self-made implementation, I will introduce my thoughts about the New Oracle Database Release Model.



DBMS_AUDIT_MGMT.CLEAN_AUDIT_TRAIL not working on 12c? Here’s why…

Posted on by
5

It is bad to realize, after a few years, that my customer’s Audit Cleanup procedures are not working properly for every database…

NOTE: The post is based on standard audit, not unified audit.

My customer developed a quite nice procedure for database housekeeping (including diag dest, OS audit trail, recyclebin, DB audit…)

But after some performance problems, I have come across the infamous sql_id 4ztz048yfq32s:

This SQL comes from the “Failed Logon Attempts” metric in Enterprise Manager.

I’ve checked the specific database, and the table SYS.AUD$ was containing way too many rows, dating before our purge time:

The cleanup procedure does basically this:

But despite a retention window of 31 days, the rows are still there:

(today is 27.04.2018, so the oldest records are more than 1 year old)

I’ve checked with ASH, the actual delete statement executed by the clean_audit_trail procedure is:

So, the DBID clause is OK, but the NTIMESTAMP# clause is  not!

Why?

Long story long (hint, it’s a bug: 19958239)
Update 30.05.2018 the solution is explained in this Doc: 2068066.1, thanks John)

The cleanup metadata is stored into the view DBA_AUDIT_MGMT_LAST_ARCH_TS. Its structure in 11g was:

But in 12c, there are 2 new columns:

When the database is upgraded from 11g to 12c, the two new columns are set to “0” by default.

But when the procedure DBMS_AUDIT_MGMT.SET_LAST_ARCHIVE_TIMESTAMP is executed, the actual dbid is used, and new lines appear:

It is clear now that the DELETE statement is not constructed properly. It should get the LAST_ARCHIVE_TS of the actual DBID being purged… but it takes the other one.

According to my tests, it does not use neither the correct timestamp for the dbid, nor get the oldest timestamp: it uses instead the timestamp of the first record found by the clause “WHERE AUDIT_TRAIL=’STANDARD AUDIT TRAIL'”. It depends on the physical location of the row in the table! Clearly a big mess… (PS, not sure 100%, but this is what I suppose)

So, I have tried to modify the archive time for DBID 0:

Trying to execute the cleanup again, now leads to a better timestamp:

I have then tried to play a little bit with the DBA_AUDIT_MGMT_LAST_ARCH_TS view (and the underlying table DAM_LAST_ARCH_TS$).

First, I’ve faked the DBID:

Then, I have tried to increase the retention timestamp (500 days):

Finally, I have tried to purge the audit trail with both DBIDs:

As I expected, in both cases the the cleanup generated the delete with the timestamp of the fake DBID:

Is it possible to delete the unwanted records from the view DBA_AUDIT_MGMT_LAST_ARCH_TS?

Not only is possible, but I recommend it:

Afterwards, the timestamp in the where condition is correct and remains correct after subsequent executions of DBMS_AUDIT_MGMT.SET_LAST_ARCHIVE_TIMESTAMP.

Conclusions, IMPORTANT FOR THE DATABASE OPERATIONS:

The upgrade causes the unwanted lines with DBID=0 in the DBA_AUDIT_MGMT_LAST_ARCH_TS view.

Moreover, any duplicate changes the DBID: any subsequent execution of DBMS_AUDIT_MGMT.SET_LAST_ARCHIVE_TIMESTAMP in the duplicated database will lead to additional lines in the view.

This is what I plan to do now:

  • Whenever I upgrade from 11g to 12c, cleanup the data from DBA_AUDIT_MGMT_LAST_ARCH_TS and schedule the cleanup for DBID 0 as well
  • Whenever I duplicate a database, I execute a DELETE (without clauses) from DBA_AUDIT_MGMT_LAST_ARCH_T and a truncate of the table SYS.AUD$ (it is a duplicate, after all!)

HTH

BP and Patch 22652097: set optimizer_adaptive_statistics to FALSE explicitly or it might not work!

Posted on by
2

Update 14.03.2018: After some exchanges with Nigel Bayliss, the behaviour described here has been filed as unpublished bug 27626925: OPTIMIZER ADAPTIVE STATS DEFAULT FALSE NOT HONORED WHEN ENABLED IN OCT OR JAN BP. It will be fixed starting with April’s bundle patch.



According to Nigel’s blog post:

The Oracle 12.1.0.2 October 2017 BP and the Adaptive Optimizer

if you installled the patch 22652097 prior to apply the Bundle Patch 171018, the BP apply in the database should recognize that the patch was already in place and keep it activated. This is done through the fix control 26664361.

When fix_control 26664361:0 -> Patch 22652097 is not enabled: the parameter optimizer_adaptive_features (OAF) works

When fix_control 26664361:1 -> Patch 22652097 is enabled; optimizer_adaptive_features is discarded and the two new parameters have the priority: optimizer_adaptive_plans (OAP) and optimizer_adaptive_statistics (OAS).

But at my customer, I had another behavior.

My patching story might be very similar to yours!

When I started upgrading my customer’s database to 12c in early 2015, I experienced very soon the infamous problems with SQL Plan Directives (SPD) and Adaptive Dynamic Sampling (ADS) that I described in my paper: ADAPTIVE FEATURES OR: HOW I LEARNED TO STOP WORRYING AND TROUBLESHOOT THE BOMB .

Early fixes

When I was new to the problem, the quick fix for the problematic applications was to set OAF to FALSE.

Later, I discovered some more details and decided to opt for setting:

In other cases, I disabled the specific directives that were causing problems.

But many databases did not have so many problems, and I left the defaults.

Patch 22652097 on top of BP170718

At some point, me and my customer decided to apply the fix 22652097, on top of BP170718 that was our current patch level at that time.

The patch installation on a test database was complaining about the optimizer_adaptive_feature set: this parameter was not used anymore. This issue is nicely explained by Flora in her post Patch 22652097 in 12.1 makes optimizer_adaptive_features parameter obsolete.

In order to apply that patch on the remaining databases, we did:

  • alter system reset optimizer_adaptive_features;
  • alter system reset “_optimizer_dsdir_usage_control”;
  • Applied the patch on binaries and datapatch on the databases.

The result at this point was that:

  • optimizer_adaptive_features was not set
  • optimizer_adaptive_plans was set to true
  • optimizer_adaptive_statistics was set to false.

It might seems superflous to say, but it’s not, the SQL Plan Directives were not used anymore: no Adaptice Dynamic Sampling and no performance problems.

Bundle Patch 180116

Three weeks ago, we installled the last Bundle Patch in order to fix some Grid Infrastructure problems, and the BP, as described in Nigel’s note (and Mike Dietrich and many other bloggers :-)) contains the patch 22652097.

According to Nigel’s post, the patch installation should have detected that the patch 22652097 was already there and activate it.

And indeed, after we applied the BP, the fix_control 26664361 was set to 1 (that means that the patch 22652097 is enabled). So we went live with this setup without additional checks.

One week later, we started experiencing performance problems again. I noticed immediately that the Adaptive Dynamic Sampling was very aggressive again, and the SQL Plan Directives used again.

But the fix was there AND ENABLED!

After a few tests, I realized that the SPD is not used anymore if I set optimizer_adaptive_statistics EXPLICITLY to false.

optimizer_adaptive_statistics must be set explicitly, the default does not work

And here’s the proof:

I use once again the great SPD example by Tim Hall (sorry Tim, it’s not the first time that I steal your work 🙂 ) . You can find here:

SQL Plan Directives in Oracle Database 12c Release 1 (12.1)

After applying the BP, I have the default parameter, not set explicitly, and the fix_control enabled:


If I run the test statement (again, find it here https://oracle-base.com/articles/12c/sql-plan-directives-12cr1) the directives are used:


but then I set the parameter explicitly:

and the SPD usage (and consequently, ADS), are gone:

Conclusion

Set the parameter EXPLICITLY when you apply the BP that contains the fix.

And ALWAYS test the behavior!

You can check how many statements use the dynamic sampling by following this short blog post by Dominic Brooks:

Which of my sql statements are using dynamic sampling?

HTH

Get the Most out of Oracle Data Guard – The material

Posted on by
6

Here we go: as usual, the feedback that I usually get after my talks (specifically, after POUG High Five conference), is if I will share my demo scripts and material.

Sadly, the demos I am doing for my presentation “Get the most out of Oracle Data Guard” are quite tied to an environment built for the purpose of the demos. So, do not expect to get scripts easy to use as is, but rather to get some ideas beyond the demo themselves.

I hope they will help to get the whole picture.

Of course, if you need to implement a cloning strategy based on Data Guard or any other solution that I describe in this post, please feel free to contact me, I will be glad to help you implement it in your environment.

Slides

Demo 1

Video:

Scripts:



Demo 2

Video:


Scripts:



Demo 3

Video:

Scripts:

Preparation:

snap_acfs.pl



snap_databasae.pl

clone_from_snap.pl
