java -jar dms.jar [dmstool options]

java -jar dms.jar -dump -a "youraddress://..." [format=xml]

java -jar dms.jar -a "youraddress://..." metric metric ...

java -jar dms.jar -a "youraddress://..." -table table table ...

opmn://asserver:6003
http://asserver:7200/dms0/Spy
ajp13://asserver:3301/dmsoc4j/Spy

 java -jar dms.jar ... | awk -f parse_output.awk

####################
# parse_output.awk #
####################

#function pl() replaces all non alphanumeric occurrences with an underscore
function pl(input) {
        return gensub("[^[:alnum:]_-]","_","G",input);
}

# function get_rrd_path() returns a path where the rrd files should be placed
# I should rewrite a new path for each dms table... I'll skip many of them
function get_rrd_path() {
        if (table == "mod_oc4j_destination_metrics")
                return sprintf("%s/%s/%s/%s.rrd", record["Host"],
                    pl(table), pl(record["Name.value"]), pl(var) );
        if (table == "mod_oc4j_mount_pt_metrics")
                return sprintf("%s/%s/%s/%s/%s.rrd", record["Host"],
                    pl(table), pl(record["Destination.value"]), pl(record["Name.value"]), pl(var) );
        if (table == "ohs_server")
                return sprintf("%s/%s/%s.rrd", record["Host"], pl(table), pl(var) );
        if (table == "JVM")
                return sprintf("%s/%s/%s/%s.rrd", record["Host"],
                    pl(table), pl(record["Process"]), pl(var) );
        if (table == "opmn_process")
                return sprintf("%s/%s/%s/%s/%s/%s/%s/%s.rrd", record["Host"], pl(table),
                  pl(record["iasInstance.value"]), pl(record["opmn_ias_component"]),
                  pl(record["opmn_process_type"]),pl(record["opmn_process_set"]),
                  pl(record["Name"]), pl(var) );

        return sprintf("%s/%s/%s.rrd", record["Host"], pl(table), pl(var) );
}
# function process_record actually does the dirty work of invoking the update script
function process_record() {
        #every record has a timeStamp.ts metric that I should use to update my rrd
        ts=substr(record["timeStamp.ts"],0,10);
        for ( var in record ) {
        if ( var != "timeStamp.ts" && record[var] ~ /^[[:digit:]]+$/ ) {
            if ( var ~ /\.(count|completed|time)$/ ) {
                dstype="DERIVE";
            } else {
                if ( var == "responseSize.value" ) {
                    dstype="DERIVE";
                } else {
                    dstype="GAUGE";
                }
            }
            rrdFile=sprintf("/path_to_data/%s",get_rrd_path());
            #### update_metric_rrd is a shell script listed below!!!!!
            cmd=sprintf("/path_to_scripts/update_metric_rrd %s %s %d %d",
                rrdFile,dstype,ts,record[var]);
            system(cmd);
            }
        }
}

# parse_record() populates an hash array
# with all metrics belonging to the table record
function parse_record() {
    #print "RRRR -  START OF RECORD (table " table ")"
    delete record
    while ( ! /^$/ ) {
        # I'm parsing the record as far I'm in this while statement
        # the array hash is the name of the dms metric basename.
        # $1 is the metric name but I have to trim the final ":"
        key=substr($1,0,length($1)-1)
        record[key]=$2
        getline
    }
    # this function is included in funcions.awk:
    # I invoke it to process the record I've just parsed
    process_record();
}
BEGIN {
    # as far as started is 0, I've never reached the first table
    started=0
}

#MAIN
{
    # I jump over the first lines until I reach the first table
    if (started==0) {
        while ( ! /^---/ ) {
           getline
        }
        started=1
    }

    # looking for the next occurrence of a table
    # all tables start with:
    # ----------
    # table_name
    # ----------
    if ( /^---/ ) {
        # first table reached: the next row is my table name,
        # then I reach again a dashed line -----
        getline table
        getline trash
        #print ""
        #print "##########################"
        print "  TABELLA " table
        #print "##########################"
        next
    }

    if ( ! /^$/ ) {
        # reached an empty line: could be the end of a record or the and of a table
        # since a new table is threated in previous "if" statement, I'm starting a new record.
        parse_record()
    }

}

END {
}

#!/bin/bash
RRDFILE=$1
DSTYPE=$2
TS=$3
VALUE=$4

rrdtool update $RRDFILE ${TS}:${VALUE}

if [ $? -ne 0 ] ; then
        DIR=`dirname $RRDFILE`

        [ -d $DIR ] || mkdir -p $DIR
        [ -f $RRDFILE ] || rrdtool create $RRDFILE -b "now-1month" -s 1800 \
                DS:metric:${DSTYPE}:7200:0:U \
                RRA:AVERAGE:0.5:1:672 \
                RRA:AVERAGE:0.5:4:1080 \
                RRA:AVERAGE:0.5:12:1460 \
                RRA:AVERAGE:0.5:48:1095 \
                RRA:MAX:0.5:4:1080 \
                RRA:MAX:0.5:12:1460 \
                RRA:MAX:0.5:48:1095 \
                RRA:LAST:0.5:1:672
        rrdtool update $RRDFILE ${TS}:${VALUE}
fi

rrdtool graph - -s "end-${hours}hours" -e $end \
                -v "Requests Completed/sec" \
        -w 640 -h 240 --slope-mode \
                -t "HTTP Requests for www.ludovicocaldara.net" \
                DEF:1request_completed=/data/wwwserver1/ohs_server/request_completed.rrd:metric:AVERAGE \
                DEF:2request_completed=/data/wwwserver2/ohs_server/request_completed.rrd:metric:AVERAGE \
                CDEF:request_completed=1request_completed,2request_completed,+ \
                VDEF:slope=request_completed,LSLSLOPE \
                VDEF:lslint=request_completed,LSLINT \
                CDEF:reg=request_completed,POP,slope,COUNT,*,lslint,+ \
                LINE1:reg#666666:"Regression" \
                AREA:1request_completed#4040AA:"wwwserver1"  \
                AREA:2request_completed#6666FF:"wwwserver1":STACK  \
        > mygraph.png
